Color
Choose your color: BLUE CRUSH-Collection
Size
Choose your size
Component configuration
They ensure quality, durability and superior performance on every journey
ERGONOMIC MEASURES
Couldn't load pickup availability
*The components that are shown may not correspond to the image of this specific model.
View full details
Specifications
Components
-
Frame
Taurus Adventure, MTB XCO Geometry BGC, Aluminum 3BS 6061 Hydroforming, BB92 Bottom bracket, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2" - 1-1/2", Post Mount 160mm, 29x2,40" maximum tyre, BOOST Thru axle 12x148mm, UDH Standard
-
Fork
RockShox Judy TK, Damper Type Turnkey, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Tapered steerer, Rake 51mm, 30mm straight wall aluminium, Diffusion Black, 100mm travel
-
Material
Aluminum 3BS 6061 Hydroforming
-
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
-
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2, length: 350, 400mm
-
Saddle
Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm
-
Seat clamp
Universal Derailleur Hanger
-
Wheels
Avanforce TRYP30 EVO 29", 15x110, Boost 12x148mm, TLR, Center Lock, internal width 30mm
-
Control Changes
SRAM SX Eagle Trigger 12s, X-actuation
-
Gear Changes
SRAM SX Eagle, Aluminum cage, 12 speed
-
Cranks
SRAM X1 1000, DUB Eagle, 34T 170-175mm
-
Chain
SRAM SX Eagle A1, 118 Links
-
Cassette
CS PG1210 Eagle, 11-50T
-
Bottom bracket
SRAM DUB PF92 MTB
-
Brake
SRAM Level Black, 2 Piston
-
*We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.
Test, display and rental
(You can find this bike live at the following stores)
| Bike | Color | Size | Service | City | Store |
|---|
Geometry
1
Seat tube
400 mm
2
Horizontal tube
556.80 mm
3
Front angle
68°
4
Seat tube angle
76°
5
Wheelbase
1114.8 mm
6
Sheath
440 mm
7
Front tube
95 mm
8
Bottom bracket drop
65 mm
9
Trail
94.5 mm
10
Fork feed
51 mm
11
Fork length
510 mm
12
Reach
405 mm
13
Stack
608.7 mm
1
Seat tube
435 mm
2
Horizontal tube
584.1 mm
3
Front angle
68°
4
Seat tube angle
76°
5
Wheelbase
1143.6 mm
6
Sheath
440 mm
7
Front tube
105 mm
8
Bottom bracket drop
65 mm
9
Trail
94.5 mm
10
Fork feed
51 mm
11
Fork length
510 mm
12
Reach
430 mm
13
Stack
618 mm
1
Seat tube
470 mm
2
Horizontal tube
612.1 mm
3
Front angle
68°
4
Seat tube angle
76°
5
Wheelbase
1171.9 mm
6
Sheath
440 mm
7
Front tube
115 mm
8
Bottom bracket drop
65 mm
9
Trail
94.5 mm
10
Fork feed
51 mm
11
Fork length
510 mm
12
Reach
455 mm
13
Stack
630.2 mm
1
Seat tube
500 mm
2
Horizontal tube
638.7 mm
3
Front angle
68°
4
Seat tube angle
76°
5
Wheelbase
1201.1 mm
6
Sheath
440 mm
7
Front tube
125 mm
8
Bottom bracket drop
65 mm
9
Trail
94.5 mm
10
Fork feed
51 mm
11
Fork length
510 mm
12
Reach
480 mm
13
Stack
636.5 mm
Detailed geometry: TAURUS ADV SX
| XS | S | M | L | |
|---|---|---|---|---|
| 150-160 cm | 160-170 cm | 170-180 cm | 180-190 cm | |
| 1 Seat tube | 400 mm | 435 mm | 470 mm | 500 mm |
| 2 Horizontal tube | 556.80 mm | 584.1 mm | 612.1 mm | 638.7 mm |
| 3 Front angle | 68° | 68° | 68° | 68° |
| 4 Seat tube angle | 76° | 76° | 76° | 76° |
| 5 Wheelbase | 1114.8 mm | 1143.6 mm | 1171.9 mm | 1201.1 mm |
| 6 Sheath | 440 mm | 440 mm | 440 mm | 440 mm |
| 7 Front tube | 95 mm | 105 mm | 115 mm | 125 mm |
| 8 Bottom bracket drop | 65 mm | 65 mm | 65 mm | 65 mm |
| 9 Trail | 94.5 mm | 94.5 mm | 94.5 mm | 94.5 mm |
| 10 Fork feed | 51 mm | 51 mm | 51 mm | 51 mm |
| 11 Fork length | 510 mm | 510 mm | 510 mm | 510 mm |
| 12 Reach | 405 mm | 430 mm | 455 mm | 480 mm |
| 13 Stack | 608.7 mm | 618 mm | 630.2 mm | 636.5 mm |
Technologies
Size: XS / Color: BLUE CRUSH-Collection
950,00€
