URSUS ELITE

URSUS ELITE

eBIKES / eBike

Ir directamente a la información del producto
ICS2  FULL INTERNAL CABLE SYSTEM
MACH-R Nanotech
HM2X
MONOCOQUE

URSUS ELITE

URSUS ELITE

eBIKES / eBike

Color

Elige tu color: DARK GREY-Collection

Color Collection

Talla

Elige tu talla

*Los componentes que se muestran pueden no corresponder a la imagen de este modelo en concreto.

Ver todos los detalles

Especificaciones

Componentes

  • Horquilla

    Rock Shox SID Select RL, Damper Type Charger RL, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Rake 44mm, Tapered steerer, 35 mm tapered wall aluminium, Diffusion Black, 120mm travel, weight: 1671gr

  • Material

    Full carbon fiber HM2X

  • Manillar

    Avanforce AF3, Aluminum 6061, Ø31,8mm, wide 740mm, weight 330gr

  • Tija sillín

    Crank Brothers HIGHLINE 3 Dropper post, Aluminum 7075-T6, 0 offset, Ø30,9, 125mm travel, weight: 609gr

  • Sillín

    Essax Era, Steel rails, length: 250mm, width: 145mm, weight: 280gr

  • Patilla

    Universal Derailleur Hanger

  • Ruedas

    Mavic E-Crossride 29", 15x110, Boost 12x148mm, TLR, MS12 Rear Hub, 6 Bolts, internal width: 30mm, weight: 2225gr

  • Cambios Mandos

    SRAM GX Eagle Trigger 12V, X-actuation, weight 133g

  • Cambios Gear

    SRAM GX Eagle Lunar, Aluminum cage, 12 Speed

  • Desviador

    SRAM GX Eagle Lunar, Aluminum cage, 12 Speed

  • Bielas

    FSA CK-220/IS Wider MTB Alloy Cranks, 170mm

  • Cadena

    SRAM SX Eagle A1, 118 links

  • Cassette

    SRAM XG 1275 Eagle, 11-52T

  • Freno

    SRAM DB8 Black 4 Piston

  • Motor

    POLINI EP3+ Tunning BR HYBRID Engine Control Unit , Shft Control Unit, Nominal power 250W - 75Nm, Peak power 500W, Q Factor 144mm

  • Batería

    POLINI EVO 500Wh 36V 13,8Ah

  • Display

    POLINI Color display TFT 3" High-contrast LCD, APP 3 Engine Maps TOURING - DYNAMIC - RACE, 10 features, USB port, Bluetooth comunication, ANT+ comunication, MTB handlebar support

  • Cargador

    Polini EP3 EVO Charger UE 220-240V 3A

  • *Nos reservamos el derecho a modificar la información y los componentes de los productos que aparecen en esta web sin previo aviso, incluido el equipamiento, las especificaciones, modelos, colores y materiales.

Geometría

berria-production/frames/25.01.20/12._URSUS.webp

1

Tubo de sillín

400 mm

2

Tubo horizontal

583 mm

3

Ángulo frontal

68,2°

4

Ángulo del tubo de sillín

74°

5

Distancia entre ejes

1114,4 mm

6

Vaina

435 mm

7

Tubo frontal

95 mm

8

Caída eje pedalier

42 mm

9

Trail

103,8 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

531 mm

12

Alcance del cuadro

410 mm

13

Altura del cuadro

602 mm

1

Tubo de sillín

445 mm

2

Tubo horizontal

620 mm

3

Ángulo frontal

68,2°

4

Ángulo del tubo de sillín

73,6°

5

Distancia entre ejes

1148,1 mm

6

Vaina

435 mm

7

Tubo frontal

105 mm

8

Caída eje pedalier

42 mm

9

Trail

103,8 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

531 mm

12

Alcance del cuadro

440 mm

13

Altura del cuadro

611 mm

1

Tubo de sillín

490 mm

2

Tubo horizontal

658 mm

3

Ángulo frontal

68,2°

4

Ángulo del tubo de sillín

73,2°

5

Distancia entre ejes

1181,7 mm

6

Vaina

435 mm

7

Tubo frontal

115 mm

8

Caída eje pedalier

42 mm

9

Trail

103,8 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

531 mm

12

Alcance del cuadro

470 mm

13

Altura del cuadro

621 mm

Tecnologías

berria-production/technologies/ics2/ics2.svg
berria-production/technologies/ics2/ics2.svg

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.

berria-production/technologies/3fc5e540-4886-4ecb-8acd-1afd0eb1898d/MACH-R_Nanotech_d9b9a3cf-c9d7-47f5-8f3e-1bcf23d98b25.svg
berria-production/technologies/3fc5e540-4886-4ecb-8acd-1afd0eb1898d/MACH-R_Nanotech_d9b9a3cf-c9d7-47f5-8f3e-1bcf23d98b25.svg

To deal with the additional forces and high-frequency vibrations that a motor and battery system exert on a carbon frameset, we use MACH-R Nanotech resin. This special resin bonds the Toray fibres of HM2X carbon together, providing the superior mechanical strength required for an electric motorised frame, improving frame strength, resilience and long-term lifespan.

berria-production/technologies/a59da7ea-81e7-46c0-be98-cbfaaa8f1487/hm2x.svg
berria-production/technologies/a59da7ea-81e7-46c0-be98-cbfaaa8f1487/hm2x.svg

HM2X carbon is engineered using T700 and T800 Toray intermediate-modulus fibres. Used strategically across key frame areas, this dual blend of carbon material is laid up to produce an optimal combination of stiffness while also prioritising comfort.

berria-production/technologies/monocoque/monocoque.svg
berria-production/technologies/monocoque/monocoque.svg

Monocoque technology makes the front triangle in a single piece using a specific curing protocol and internal mold sliders made of different special grade steel. This technology is used to achieve frames where strength, lightness and rigidity prevail.

Talla: S / Color: DARK GREY-Collection

3.999,00€
