ALUMINUM 3BS
ICS2 FULL INTERNAL CABLE SYSTEM
O2HS OVERSIZED HEADSET
HP FORGED
ALLROAD ADV APEX MULLET
FS ALLROAD

ALLROAD ADV GRX400

ALLROAD ADV GRX400

Gravel

Color

Choose your color: DESERT STORM-Collection

Color Collection

Size

Choose your size

*The components that are shown may not correspond to the image of this specific model.

View full details

Specifications

Components

  • Frame

    Allroad HPR 2G, Gravel Type 1-2 Geometry BGC, Aluminum 3BS 6061 Hydroforming, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2" - 1-1/2", Flat Mount 140mm, 700x42c maximum tyre, Thru axle 12x142mm, UDH Standard

  • Fork

    Allroad EVO 3, full carbon, internal cable system ICS2, 1-1/8" - 1-1/2" Tapered , Flat Mount Standard max. 160mm disc , 700x50c maximum tyre, 51mm fork rake, 395mm axle to crown, Thru axle 12x100mm

  • Material

    Aluminum 3BS 6061 Hydroforming

  • Handlebar

    Avanforce 3 Gravel, Alloy 6061, Ø31,8, width: 400, 420, 440mm

  • Seatpost

    Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2, length: 350, 400mm

  • Saddle

    Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm

  • Seat clamp

    Universal Derailleur Hanger

  • Wheels

    Avanforce Sniper24 700C, 12x100, Thru Axle 12x142mm, SH11 Rear Hub, Center Lock, internal width 24mm

  • Control Changes

    SHIMANO GRX400, ST-RX400, 10s

  • Gear Changes

    SHIMANO GRX400, RD-RX400, 10s

  • Derailleur

    SHIMANO GRX400, FD-RX400, 10s

  • Cranks

    SHIMANO GRX FC-RX600-10, Crankset 46/30T, 170-172,5-175mm

  • Chain

    CN-HG54, 116 Links

  • Cassette

    CS-HG62-10, 11-36T

  • Bottom bracket

    Shimano BB86 Press Fit, Black

  • Brake

    SHIMANO BR-RX400, Hydraulic Disc Brake

  • *We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.

Test, display and rental

(You can find this bike live at the following stores)

Near me
Bike Color Size Service City Store

Geometry

berria-production/frames/26.01.14/7._ALLROAD_HPR.png
XS 155-165 cm
S 165-175 cm
M 175-185 cm
L 185-192 cm
XL >192 cm

1

Seat tube

460 mm

2

Horizontal tube

525.1 mm

3

Front angle

70°

4

Seat tube angle

74°

5

Wheelbase

1006.5 mm

6

Sheath

416 mm

7

Front tube

100 mm

8

Bottom bracket drop

77 mm

9

Trail

82 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

371.4 mm

13

Stack

535.9 mm

1

Seat tube

484 mm

2

Horizontal tube

542.4 mm

3

Front angle

70.5°

4

Seat tube angle

73.75°

5

Wheelbase

1018.1 mm

6

Sheath

416 mm

7

Front tube

125 mm

8

Bottom bracket drop

77 mm

9

Trail

78.7 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

378.37 mm

13

Stack

561.5 mm

1

Seat tube

508 mm

2

Horizontal tube

555 mm

3

Front angle

71°

4

Seat tube angle

73.5°

5

Wheelbase

1023.9 mm

6

Sheath

416 mm

7

Front tube

130 mm

8

Bottom bracket drop

75 mm

9

Trail

75.3 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

387.1 mm

13

Stack

566.2 mm

1

Seat tube

532 mm

2

Horizontal tube

570 mm

3

Front angle

71.5°

4

Seat tube angle

73.5°

5

Wheelbase

1035 mm

6

Sheath

416 mm

7

Front tube

150 mm

8

Bottom bracket drop

75 mm

9

Trail

72 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

396.1 mm

13

Stack

587 mm

1

Seat tube

556 mm

2

Horizontal tube

592.4 mm

3

Front angle

72°

4

Seat tube angle

73.5°

5

Wheelbase

1053 mm

6

Sheath

416 mm

7

Front tube

177 mm

8

Bottom bracket drop

75 mm

9

Trail

68.7 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

410.3 mm

13

Stack

614 mm

Technologies

technologies/3ecafc71-5b06-45c9-87b2-40549fe3019b/ALUMINIUM_6dfda451-b332-4d9c-ab49-1c66a44cb78e.png
technologies/3ecafc71-5b06-45c9-87b2-40549fe3019b/ALUMINIUM_6dfda451-b332-4d9c-ab49-1c66a44cb78e.png

The 3BS technique is based on the hydroforming process. The tubes are pressed and then pressurized to achieve variable wall thicknesses along the span. The technology ensures a good stiffness to strength ratio without compromising the weight of the final product.

berria-production/technologies/ics2/ics2.svg
berria-production/technologies/ics2/ics2.svg

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.
berria-production/technologies/7d17f861-c924-4d10-b18c-2f2d6b0f964e/O2HS_OVERSIZED_HEADSET_ed8e4857-fec2-4f6c-bd14-9f66e79377bf.svg
berria-production/technologies/7d17f861-c924-4d10-b18c-2f2d6b0f964e/O2HS_OVERSIZED_HEADSET_ed8e4857-fec2-4f6c-bd14-9f66e79377bf.svg

The 1.5 -1.5 oversized steering system increases the rigidity of the head tube, providing more precise and safer driving, increasing stability when cornering.
technologies/e67373da-64c1-4f77-9d21-94dd4e6ac400/HP FORGED-1.png
technologies/e67373da-64c1-4f77-9d21-94dd4e6ac400/HP FORGED-1.png

The HPF (High Pressure Forging) technology is able to mold the aluminum alloy into complex shapes achieving great mechanical performance. Berria uses this key tech in bicycle parts that need strength and resiliance such as motor mounts and dropouts.

Size: XS / Color: DESERT STORM-Collection

1.599,00€
