E-BRAVO HPR ELITE NX

E-BRAVO HPR ELITE NX

eBIKES / Montaña

ICS2 FULL INTERNAL CABLE SYSTEM
ACTIVE STAY
ALUMINUM 3BS

E-BRAVO HPR ELITE NX

E-BRAVO HPR ELITE NX

eBIKES / Montaña

Color

Choose your color: BLACK-WHITE PEARL-BLUE ELECTRO-BRILLO

Size

Choose your size

*The components that are shown may not correspond to the image of this specific model.

View full details

Specifications

Components

  • Frame

    E-Bravo HPR, 3BS 6061 Hydroformed and aluminum parts with Technology PCP Precision Casting Process, Full internal cable system ICS2, Headset integrated OH2S 1-1/2" - 1-1.8", Post mount 180mm, 29x2.35" maximum tyre, Thru axle Boost 12x148mm, UDH Standard, weight: 2700gr

  • Fork

    RockShox 35 GOLD RL, Motion Control, 15x110mm Maxle Stealth, Tapered steerer, Rake 44mm, 35mm straight wall steel, Fast Black, 120mm travel, weight: 2277gr

  • Material

    Aluminum 3BS 6061 Hydroforming

  • Handlebar

    Avanforce AF2 MTB, Aluminum 6061, Ø31,8mm, width 780mm, Backsweep 6°, Upsweep 5°, Rise 20mm, weight: 330gr

  • Seatpost

    TRANZX JD-YSPJL Aluminum 7075-T6, 0 offset, Ø31,6, 120mm travel, weight: 590gr

  • Saddle

    Essax Era, Steel rails, length: 250mm, width: 145mm, weight: 280gr

  • Seat clamp

    Universal Derailleur Hanger

  • Shock absorber

    RockShox Super Deluxe SEL + Berria Mako GT Custom Tunning, Debon Air, Trunnion 185X55mm, 151mm travel

  • Wheels

    Mavic E-Crossride 29", 15x110, Boost 12x148mm, TLR, HG11 Rear Hub, 6 Bolts, internal width: 30mm, weight: 2225gr

  • Coverings

    Vittoria Barzo 29x2,35", Tubeless ready, Graphene 2.0, 120 TPI, weight: 820gr

  • Control Changes

    SRAM NX Eagle Trigger 12V, X-actuation

  • Gear Changes

    SRAM NX Eagle, Aluminum cage, 12 Speed

  • Derailleur

    SRAM NX Eagle, Aluminum cage, 12 Speed

  • Cranks

    Bafang Aluminum Alloy Cranks, 165-170mm, 34T

  • Chain

    SRAM SX Eagle A1, 118 links

  • Cassette

    SRAM PG 1210 Eagle, 11-50T

  • Brake

    SRAM DB8 Black 4 Piston

  • *We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.

Geometry

S 155-175 cm
M 175-190 cm
L 185-200 cm

1

Seat tube

410 mm

2

Horizontal tube

580 mm

3

Front tube

115 mm

4

Sheath

425 mm

5

Bottom bracket drop

68 mm

6

Wheelbase

1162 mm

7

Front angle

66,5°

8

Seat tube angle

74°

9

Reach

412 mm

10

Stack

639 mm

1

Seat tube

445 mm

2

Horizontal tube

615 mm

3

Front tube

115 mm

4

Sheath

452 mm

5

Bottom bracket drop

68 mm

6

Wheelbase

1172 mm

7

Front angle

68°

8

Seat tube angle

73°

9

Reach

436 mm

10

Stack

645 mm

1

Seat tube

500 mm

2

Horizontal tube

645 mm

3

Front tube

120 mm

4

Sheath

452 mm

5

Bottom bracket drop

68 mm

6

Wheelbase

1202 mm

7

Front angle

68°

8

Seat tube angle

73°

9

Reach

464 mm

10

Stack

650 mm

Technologies

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.

Our Active Stay Technology increases vertical flexion of the seat stays without compromising the necessary rigidity for a responsive ride.The result is maximised traction and ride compliance over the toughest terrain, with direct transfer of power translating into more speed.

The 3BS technique is based on the hydroforming process. The tubes are pressed and then pressurized to achieve variable wall thicknesses along the span. The technology ensures a good stiffness to strength ratio without compromising the weight of the final product.

Size: S / Color: BLACK-WHITE PEARL-BLUE ELECTRO-BRILLO

2.799,00€
