MAKO ELITE DEORE

MAKO ELITE DEORE

Montaña

products/ddee3f77-95d9-45b1-9a87-b5c987f027a7/PT26.05.01.S1.L-1.png
products/ddee3f77-95d9-45b1-9a87-b5c987f027a7/PT26.05.01.S1.L-2.png
products/ddee3f77-95d9-45b1-9a87-b5c987f027a7/PT26.05.01.S1.L-3.png
ICS2 FULL INTERNAL CABLE SYSTEM
IN-LINK
HM2X
MONOCOQUE

MAKO ELITE DEORE

MAKO ELITE DEORE

Montaña

Color

Elige tu color: STEELBLUE-Collection

Color Collection

Talla

Elige tu talla

*Los componentes que se muestran pueden no corresponder a la imagen de este modelo en concreto.

Ver todos los detalles

Especificaciones

Componentes

  • Cuadro

    Mako 4

  • Horquilla

    RockShox SID BSE, Damper Charger RL, Remote Lockout 3 Position, 15x110 Maxle Stealth, Tapered steerer, Spring Debon Air, Rake 44mm, 35mm tapered wall aluminum, Diffusion Black, 120mm travel

  • Material

    Full carbon fiber HM2X

  • Manillar

    Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm

  • Tija sillín

    Avanforce Tibia, Softex Seat post, UD Carbon, 0 offset, Ø31,6 x 420mm

  • Sillín

    SRX Open Cut Athletic, Steel rails, length: 260mm, width: 148mm

  • Patilla

    Universal Derailleur Hanger

  • Amortiguador

    RockShox SIDLuxe Ultimate, BERRIA MAKO 4 WC XCO Tunning, Debon Air, Remote Lockout 3 Position, Trunnion 165X45, 113mm travel

  • Ruedas

    Avanforce TRYP30 EVO 29", 15x110, Boost 12x148mm, TLR, Center Lock, internal width 30mm

  • Cambios Mandos

    Shimano Deore, SL-M6100-R, 12s, Rapidfire Plus

  • Cambios Gear

    Shimano Deore RD-M6100, Aluminum Cage, 12s

  • Bielas

    RACEFACE Affect, 34T, 170-175mm

  • Cadena

    CN-M6100, 118 Links

  • Cassette

    CS-M6100-12, 10-51T

  • Bujes

    BB92 SH PF

  • Freno

    Shimano Deore, BL-6100, 4 Piston

  • *Nos reservamos el derecho a modificar la información y los componentes de los productos que aparecen en esta web sin previo aviso, incluido el equipamiento, las especificaciones, modelos, colores y materiales.

Geometría

berria-production/frames/25.01.14/mako-cuadro.webp
S 155-170 cm
M 170-185 cm
L 180-195 cm

1

Tubo de sillín

400 mm

2

Tubo horizontal

580 mm

3

Ángulo frontal

67°

4

Ángulo del tubo de sillín

76.2°

5

Distancia entre ejes

1143 mm

6

Vaina

430 mm

7

Tubo frontal

85 mm

8

Caída eje pedalier

47 mm

9

Trail

112 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

521 mm

12

Alcance del cuadro

435 mm

13

Altura del cuadro

590 mm

1

Tubo de sillín

445 mm

2

Tubo horizontal

608 mm

3

Ángulo frontal

67.5°

4

Ángulo del tubo de sillín

76°

5

Distancia entre ejes

1165 mm

6

Vaina

430 mm

7

Tubo frontal

95 mm

8

Caída eje pedalier

47 mm

9

Trail

108 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

521 mm

12

Alcance del cuadro

458 mm

13

Altura del cuadro

602 mm

1

Tubo de sillín

490 mm

2

Tubo horizontal

640 mm

3

Ángulo frontal

68°

4

Ángulo del tubo de sillín

75.8°

5

Distancia entre ejes

1191 mm

6

Vaina

430 mm

7

Tubo frontal

105 mm

8

Caída eje pedalier

47 mm

9

Trail

104 mm

10

Avance horquilla

44 mm

11

Longitud horquilla

521 mm

12

Alcance del cuadro

485 mm

13

Altura del cuadro

614 mm

Tecnologías

berria-production/technologies/ics2/ics2.svg
berria-production/technologies/ics2/ics2.svg

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.
berria-production/technologies/in-link/inlink.svg
berria-production/technologies/in-link/inlink.svg

The IN-LINK suspension system allows to integrate the shock absorber, inverted with trunnion mount, inside the front triangle, with a SAG indicator on the left side of the frame and access for its adjustment and manipulation. Thanks to a patented cover located on the front face of the opening on the frame. This integration not only results in better protection of the shock absorber against mud or dust, but also takes advantage of an improved mass distribution and a lower bike centre of gravity, which increases stability, especially at high speeds.
berria-production/technologies/a59da7ea-81e7-46c0-be98-cbfaaa8f1487/hm2x.svg
berria-production/technologies/a59da7ea-81e7-46c0-be98-cbfaaa8f1487/hm2x.svg

HM2X carbon is engineered using T700 and T800 Toray intermediate-modulus fibres. Used strategically across key frame areas, this dual blend of carbon material is laid up to produce an optimal combination of stiffness while also prioritising comfort.
berria-production/technologies/monocoque/monocoque.svg
berria-production/technologies/monocoque/monocoque.svg

Monocoque technology makes the front triangle in a single piece using a specific curing protocol and internal mold sliders made of different special grade steel. This technology is used to achieve frames where strength, lightness and rigidity prevail.

Talla: S / Color: STEELBLUE-Collection

3.299,00€
