Specifications
Components
-
Frame
Bravo 5 EVO, XCO Racing Geometry BGC, Full carbon HMR2X, Triple monocoque, resin Matrix Nanotech CNT, BB92 botton bracket, Active Stay, Asymmetric, Full internal cable system ICS2, Headset semi integrated OH2S 1-1/2", Post Mount brake, 29x2.35" maximum tyre.
-
Fork
RockShox Judy TK, Damper Type Turnkey, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Tapered steerer, Rake 51mm, 30mm straight wall aluminium, Diffusion Black, 100mm travel
-
Material
Full carbon fiber HMR2X
-
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
-
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2, length: 350, 400mm
-
Saddle
Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm
-
Seat clamp
Universal Derailleur Hanger
-
Wheels
Avanforce TRYP30 EVO 29", 15x110, Boost 12x148mm, TLR, Center Lock, internal width 30mm
-
Control Changes
SRAM SX Eagle Trigger 12s, X-actuation
-
Gear Changes
SRAM SX Eagle, Aluminum cage, 12s
-
Cranks
SRAM X1 1000, DUB Eagle, 34T 170-175mm
-
Chain
SRAM SX Eagle A1, 118 Links
-
Cassette
CS PG1210 Eagle, 11-50T
-
BB (Bottom Bracket)
SRAM DUB PF92 MTB
-
Brake
SRAM Level Black, 2 Piston
-
*We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.
Test, sale and rental
(You can find this bike live at the following stores)
| Bike | Color | Size | Service | City | Store |
|---|
Geometry
1
Seat tube
435 mm
2
Horizontal tube
514 mm
3
Front angle
71°
4
Seat tube angle
75.1°
5
Wheelbase
965 mm
6
Sheath
403 mm
7
Front tube
125 mm
8
Bottom bracket drop
74 mm
9
Trail
72.7 mm
10
Fork feed
42 mm
11
Fork length
370 mm
12
Reach
368 mm
13
Stack
526 mm
11
Maximum seatpost insertion
165 mm
1
Seat tube
475 mm
2
Horizontal tube
533 mm
3
Front angle
71.5°
4
Seat tube angle
74.7°
5
Wheelbase
980 mm
6
Sheath
403 mm
7
Front tube
141 mm
8
Bottom bracket drop
72 mm
9
Trail
69.5 mm
10
Fork feed
42 mm
11
Fork length
370 mm
12
Reach
382 mm
13
Stack
541 mm
11
Maximum seatpost insertion
165 mm
1
Seat tube
505 mm
2
Horizontal tube
551 mm
3
Front angle
72°
4
Seat tube angle
74.3°
5
Wheelbase
993 mm
6
Sheath
405 mm
7
Front tube
157 mm
8
Bottom bracket drop
72 mm
9
Trail
66.3 mm
10
Fork feed
42 mm
11
Fork length
370 mm
12
Reach
392 mm
13
Stack
558 mm
11
Maximum seatpost insertion
200 mm
1
Seat tube
535 mm
2
Horizontal tube
569 mm
3
Front angle
72.5°
4
Seat tube angle
73.9°
5
Wheelbase
1003 mm
6
Sheath
405 mm
7
Front tube
176 mm
8
Bottom bracket drop
72 mm
9
Trail
63.2 mm
10
Fork feed
42 mm
11
Fork length
370 mm
12
Reach
401 mm
13
Stack
578 mm
11
Maximum seatpost insertion
220 mm
1
Seat tube
568 mm
2
Horizontal tube
589 mm
3
Front angle
73°
4
Seat tube angle
73.5°
5
Wheelbase
1015 mm
6
Sheath
405 mm
7
Front tube
193 mm
8
Bottom bracket drop
72 mm
9
Trail
60 mm
10
Fork feed
42 mm
11
Fork length
370 mm
12
Reach
412 mm
13
Stack
596 mm
11
Maximum seatpost insertion
240 mm
Detailed geometry: BRAVO COMP SX
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| 155-165 cm | 165-175 cm | 175-185 cm | 185-192 cm | >192 cm | |
| 1 Seat tube | 435 mm | 475 mm | 505 mm | 535 mm | 568 mm |
| 2 Horizontal tube | 514 mm | 533 mm | 551 mm | 569 mm | 589 mm |
| 3 Front angle | 71° | 71.5° | 72° | 72.5° | 73° |
| 4 Seat tube angle | 75.1° | 74.7° | 74.3° | 73.9° | 73.5° |
| 5 Wheelbase | 965 mm | 980 mm | 993 mm | 1003 mm | 1015 mm |
| 6 Sheath | 403 mm | 403 mm | 405 mm | 405 mm | 405 mm |
| 7 Front tube | 125 mm | 141 mm | 157 mm | 176 mm | 193 mm |
| 8 Bottom bracket drop | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| 9 Trail | 72.7 mm | 69.5 mm | 66.3 mm | 63.2 mm | 60 mm |
| 10 Fork feed | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| 11 Fork length | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| 12 Reach | 368 mm | 382 mm | 392 mm | 401 mm | 412 mm |
| 13 Stack | 526 mm | 541 mm | 558 mm | 578 mm | 596 mm |
Technologies
Size: XS / Color: BLACK-RED RACING-Collection
1.599,00€
