Specifications
Components
-
Frame
Bravo 6, XCO WC Racing Geometry BGC with 28mm travel SOFTEX Suspension System, Full carbon HM2X, Triple monocoque, BB92 Bottom bracket, Full internal cable system ICS2, MTB Acros Headset ZS56 with Blocklock 150º, Post Mount 160mm, 29x2.40" max. tyre, BOOST Thru axle 12x148mm, UDH standard
-
Fork
RockShox RECON RL, Damper Motion Control, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Tapered steerer, Rake 51, 32 mm straight wall aluminium, Diffusion Black, 100mm travel
-
Material
Full carbon fiber HM2X
-
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
-
Seatpost
Avanforce AF3, Aluminum 6061, 0 offset, Ø27,2, length: 350, 400mm
-
Saddle
Selle Royal 2058HRN, Steel rails, length: 285mm, width: 145mm
-
Seat clamp
Universal Derailleur Hanger
-
Wheels
Avanforce TRYP30 EVO 29", 15x110, Boost 12x148mm, TLR, Center Lock, internal width 30mm
-
Control Changes
Shimano Deore, SL-M6100-R, 12s, Rapidfire Plus
-
Gear Changes
Shimano Deore RD-M6100, Aluminum Cage, 12s
-
Cranks
RACEFACE Affect, 34T, 170-175mm
-
Chain
CN-M6100, 118 Links
-
Cassette
CS-M6100-12, 10-51T
-
Bottom bracket
BB92 SH PF
-
Brake
SRAM Level Black, 2 Piston
-
*We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.
Geometry

1
Seat tube
380 mm
2
Horizontal tube
556 mm
3
Front angle
66.5°
4
Seat tube angle
75.1°
5
Wheelbase
1099 mm
6
Sheath
420 mm
7
Front tube
85 mm
8
Bottom bracket drop
63 mm
9
Trail
110 mm
10
Fork feed
44 mm
11
Fork length
516 mm
12
Reach
397 mm
13
Stack
599 mm
1
Seat tube
431 mm
2
Horizontal tube
594 mm
3
Front angle
67°
4
Seat tube angle
75.1°
5
Wheelbase
1130 mm
6
Sheath
420 mm
7
Front tube
95 mm
8
Bottom bracket drop
63 mm
9
Trail
106 mm
10
Fork feed
44 mm
11
Fork length
516 mm
12
Reach
430 mm
13
Stack
610 mm
1
Seat tube
470 mm
2
Horizontal tube
622 mm
3
Front angle
67.5°
4
Seat tube angle
74.4°
5
Wheelbase
1147 mm
6
Sheath
420 mm
7
Front tube
107 mm
8
Bottom bracket drop
63 mm
9
Trail
103 mm
10
Fork feed
44 mm
11
Fork length
516 mm
12
Reach
448 mm
13
Stack
624 mm
1
Seat tube
521 mm
2
Horizontal tube
647 mm
3
Front angle
68°
4
Seat tube angle
74.1°
5
Wheelbase
1165 mm
6
Sheath
420 mm
7
Front tube
120 mm
8
Bottom bracket drop
63 mm
9
Trail
99 mm
10
Fork feed
44 mm
11
Fork length
516 mm
12
Reach
465 mm
13
Stack
638 mm
Detailed geometry: BRAVO ELITE DEORE

XS | S | M | L | |
---|---|---|---|---|
150-165 cm | 160-175 cm | 175-185 cm | 180-198 cm | |
1 Seat tube | 380 mm | 431 mm | 470 mm | 521 mm |
2 Horizontal tube | 556 mm | 594 mm | 622 mm | 647 mm |
3 Front angle | 66.5° | 67° | 67.5° | 68° |
4 Seat tube angle | 75.1° | 75.1° | 74.4° | 74.1° |
5 Wheelbase | 1099 mm | 1130 mm | 1147 mm | 1165 mm |
6 Sheath | 420 mm | 420 mm | 420 mm | 420 mm |
7 Front tube | 85 mm | 95 mm | 107 mm | 120 mm |
8 Bottom bracket drop | 63 mm | 63 mm | 63 mm | 63 mm |
9 Trail | 110 mm | 106 mm | 103 mm | 99 mm |
10 Fork feed | 44 mm | 44 mm | 44 mm | 44 mm |
11 Fork length | 516 mm | 516 mm | 516 mm | 516 mm |
12 Reach | 397 mm | 430 mm | 448 mm | 465 mm |
13 Stack | 599 mm | 610 mm | 624 mm | 638 mm |
Technologies

Size: XS / Color: BLACK-LIQUID METAL-AQUARACER-Collection
1.999,00€
