MISTRAL HPR 105

MISTRAL HPR 105

eBIKES / eBike

ICS2 FULL INTERNAL CABLE SYSTEM
SOFTEX

MISTRAL HPR 105

MISTRAL HPR 105

eBIKES / eBike

Color

Choose your color: BLACK-Collection

Color Collection

Size

Choose your size

*The components that are shown may not correspond to the image of this specific model.

View full details

Specifications

Components

  • Frame

    Mistral HP

  • Fork

    Allroad EVO 2, full carbon, internal cable system ICS2, 1-1/8" - 1-1/2" Tapered , Flat Mount Standard max. 160mm disc , 700x45c maximum tyre, Flip-chip adust 45-51mm fork rake, 405mm axle to crown, Thru axle 12x100mm

  • Material

    Aluminum 3BS 6061 Hydroforming

  • Handlebar

    Avanforce AF3 Alloy 6061, width: 400, 420, 440mm, weight: 320gr

  • Seatpost

    Avanforce Tibia, Softex Seat post, UD Carbon, 0 offset, Ø27,2, length: 300,350,420mm

  • Saddle

    Fizik Vento Argo X5, Steel rails 7x7mm, length 265 mm, width 140 mm, weight 240g

  • Seat clamp

    Universal Derailleur Hanger

  • Wheels

    Vision Team 30 AGX, Aluminum rim, TLR, inner width 23mm, rim height 30mm, Center Lock, weight: 1920gr.

  • Control Changes

    SHIMANO 105 DISC BRAKE, ST-R7120 DUAL CONTROL, 12 SPEED

  • Gear Changes

    SHIMANO 105, RD-R7100, 12 speed

  • Derailleur

    SHIMANO 105, FD-R7100, 12 speed

  • Cranks

    FSA CK-220/IF Wider MTB Alloy Cranks, 170mm

  • Chain

    CN-M6100, HG 12-SPEED, 118 links

  • Cassette

    Shimano 105, CS-R7100, 12-SPEED, 11-34T

  • Brake

    SHIMANO BR-R7120 Hydraulic Disc

  • Motor

    POLINI EP3+ EVO Tunning BR HYBRID Engine Control Unit , Shift Control Unit, Nominal power 250W - 70Nm, Peak power 500W, Q Factor 137mm

  • Battery

    POLINI EVO 500Wh 36V 13,8Ah

  • Display

    POLINI Color display TFT 3" High-contrast LCD, APP 3 Engine Maps TOURING - DYNAMIC - RACE, 10 features, USB port, Bluetooth comunication, ANT+ comunication, ROAD handlebar support

  • Charger

    Polini EP3 EVO Charger UE 220-240V 3A

  • *We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.

Geometry

berria-production/frames/25.01.18/GEOMETRIA_25_-_MISTRAL_HPR.webp
S 165-175 cm
M 175-185 cm
L 185-192 cm
XL >192 cm

1

Seat tube

484 mm

2

Horizontal tube

5448 mm

3

Front angle

70.5°

4

Seat tube angle

73.5°

5

Wheelbase

1041 mm

6

Sheath

440 mm

7

Front tube

125 mm

8

Bottom bracket drop

77 mm

9

Trail

79 mm

10

Fork feed

45/50 mm

11

Fork length

405 mm

12

Reach

382 mm

13

Stack

562 mm

1

Seat tube

508 mm

2

Horizontal tube

555.7 mm

3

Front angle

71°

4

Seat tube angle

73.5°

5

Wheelbase

1044.2 mm

6

Sheath

440 mm

7

Front tube

130 mm

8

Bottom bracket drop

77 mm

9

Trail

75 mm

10

Fork feed

45/50 mm

11

Fork length

405 mm

12

Reach

387.1 mm

13

Stack

569.1 mm

1

Seat tube

532 mm

2

Horizontal tube

570.3 mm

3

Front angle

71.5°

4

Seat tube angle

73.5°

5

Wheelbase

1055.2 mm

6

Sheath

440 mm

7

Front tube

150 mm

8

Bottom bracket drop

75 mm

9

Trail

72 mm

10

Fork feed

45/51 mm

11

Fork length

405 mm

12

Reach

396.1 mm

13

Stack

588 mm

1

Seat tube

556 mm

2

Horizontal tube

592.6 mm

3

Front angle

72°

4

Seat tube angle

73.5°

5

Wheelbase

1073.5 mm

6

Sheath

440 mm

7

Front tube

177 mm

8

Bottom bracket drop

75 mm

9

Trail

69 mm

10

Fork feed

45/50 mm

11

Fork length

405 mm

12

Reach

410.3 mm

13

Stack

615.6 mm

Technologies

berria-production/technologies/ics2/ics2.svg
berria-production/technologies/ics2/ics2.svg

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.
berria-production/technologies/7a3bf22c-f97a-4a3a-84ef-29ca92aee3b9/SOFTEX-1.png
berria-production/technologies/7a3bf22c-f97a-4a3a-84ef-29ca92aee3b9/SOFTEX-1.png

The SOFTEX suspension system opens a new category between a Hardtail and a Full suspension bike. The first component of the system is TIBIA, a compliant carbon seat post that absorbs the small bumps across the road acting as a damper. On the other hand we have the Active Seat Stay (ASS), it is a mechanism based on sectioned shaped Seat Stays and Chain Stays with integrated bearings that together with an engineered supple Lay up helps the rider to go through rough terrain faster. All the elements mixed together will extract a total vertical travel of 28mm giving an extended comfort and higher absorption compared to a regular Hardtail bike.

Size: S / Color: BLACK-Collection

4.499,00€
