Specifications
Components
-
Frame
Stratos , Geometry Allmountain BGC, Y-Link Suspension System, Mullet standard with 160mm travel, Full carbon HM3X, Monocoque, MACH-R Nanotech, bearings full ball ISB VMAX, Full internal cable system ICS2, MTB Acros Headset ZS56 with Blocklock 150º, Post mount 200mm, 29x2.60 maximum tyre, Thru axle Boost 12x148mm, UDH standard
-
Fork
RockShox ZEB Ultimate, Damper Charger 3.1 RC2 W/Butter cups, 15x110mm Maxle Ultimate, Tapered steerer 1,5", Spring Debon Air+ W/ButterCups, Rake 44mm, 38 mm tapered wall aluminium, BoXXer Electric Red - Gloss, 160mm travel
-
Material
Full carbon fiber HM3X
-
Handlebar
Avanforce AF2 MTB, Forged Aluminum 6061, Ø31,8mm, width: 780mm, Backsweep: 6°, Upsweep: 5°, Rise: 20mm
-
Seatpost
TRANZX JD-YSPJL Aluminum 7075-T6, 0 offset, Ø31,6, 150mm travel
-
Saddle
Fizik Terra Ridon X5, Steel rails, length: 255mm, width: 145mm
-
Seat clamp
Universal Derailleur Hanger
-
Shock absorber
Rock Shox VIVID Base, 230x60, Air can, 1 token, Rebound C55, Compression tune C34, Hydraulic Bottom Out, 160mm travel
-
Wheels
Mavic E-Crossride 29"/27,5", 15x110, Boost 12x148mm, TLR, 6 Bolts, internal width 30mm
-
Control Changes
EC AXS POD Right/Left Bridge W/MMX
-
Gear Changes
SRAM X0 AXS Eagle T-TYPE, 12s
-
Cranks
GX Eagle, SRAM Powertrain ISIS Drive Cranks, length: 165mm
-
Chain
SRAM EAGLE 70 T-TYPE, 120 Links
-
Cassette
CS XS1275 Eagle, T-TYPE, 10-52T
-
Brake
SRAM Maven Silver Stealth, 4 Piston
-
Motor
SRAM Eagle Powertrain, 680W, 90Nm
-
Battery
SRAM Eagle Powertrain Full Size, 720WH, Integrated and Slidable
-
Display
SRAM Eagle Powertrain AXS Bridge Display
-
Charger
Eagle Powertrain Charger, EU/UK/US Plug Supplied
-
*We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.
Test, display and rental
(You can find this bike live at the following stores)
| Bike | Color | Size | Service | City | Store |
|---|
Geometry
1
Seat tube
400 mm
2
Horizontal tube
582 mm
3
Front angle
64.5°
4
Seat tube angle
76°
5
Wheelbase
1208 mm
6
Sheath
450 mm
7
Front tube
90 mm
8
Bottom bracket drop
-25/-6 mm
9
Trail
131.5 mm
10
Fork feed
44 mm
11
Fork length
576 mm
12
Reach
430 mm
13
Stack
610 mm
1
Seat tube
M mm
2
Horizontal tube
610 mm
3
Front angle
64.5°
4
Seat tube angle
76°
5
Wheelbase
1239 mm
6
Sheath
450 mm
7
Front tube
105 mm
8
Bottom bracket drop
-25/-6 mm
9
Trail
131.5 mm
10
Fork feed
44 mm
11
Fork length
576 mm
12
Reach
455 mm
13
Stack
623 mm
1
Seat tube
L mm
2
Horizontal tube
650 mm
3
Front angle
64.5°
4
Seat tube angle
76°
5
Wheelbase
1280 mm
6
Sheath
450 mm
7
Front tube
120 mm
8
Bottom bracket drop
-25/-6 mm
9
Trail
131.5 mm
10
Fork feed
44 mm
11
Fork length
576 mm
12
Reach
490 mm
13
Stack
637 mm
Detailed geometry: STRATOS BR+ X0 AXS
| S | M | L | |
|---|---|---|---|
| 155-170 cm | 170-185 cm | 180-195 cm | |
| 1 Seat tube | 400 mm | M mm | L mm |
| 2 Horizontal tube | 582 mm | 610 mm | 650 mm |
| 3 Front angle | 64.5° | 64.5° | 64.5° |
| 4 Seat tube angle | 76° | 76° | 76° |
| 5 Wheelbase | 1208 mm | 1239 mm | 1280 mm |
| 6 Sheath | 450 mm | 450 mm | 450 mm |
| 7 Front tube | 90 mm | 105 mm | 120 mm |
| 8 Bottom bracket drop | -25/-6 mm | -25/-6 mm | -25/-6 mm |
| 9 Trail | 131.5 mm | 131.5 mm | 131.5 mm |
| 10 Fork feed | 44 mm | 44 mm | 44 mm |
| 11 Fork length | 576 mm | 576 mm | 576 mm |
| 12 Reach | 430 mm | 455 mm | 490 mm |
| 13 Stack | 610 mm | 623 mm | 637 mm |
