STRATOS BR+ XX AXS FA

STRATOS BR+ XX AXS FA

eBIKES / Montagne

Passer aux informations produits
Y-LINK SUSPENSION SYSTEM
ICS2  FULL INTERNAL CABLE SYSTEM
EPS
HM3X
MACH-R Nanotech
MONOCOQUE

STRATOS BR+ XX AXS FA

STRATOS BR+ XX AXS FA

eBIKES / Montagne

Couleur

Choisissez votre couleur: CUSTOMIZE

Taille

Choisissez votre taille

*Les composants illustrés peuvent ne pas correspondre à l'image de ce modèle spécifique.

Afficher tous les détails

Spécifications

Composants

  • Fourche

    RockShox ZEB Ultimate Flight Attendant, Damper Charger 3.1 Flight Attendant W/Butter cups, 15x110mm Maxle Ultimate, Tapered steerer 1,5", Spring Debon Air+ W/ButterCups, Rake 44mm, 38 mm tapered wall aluminium, Gloss Black, 160mm travel

  • Matériau

    Full carbon fiber HM3X

  • Cintre

    Avanforce CONDOR, Integrated MTB Carbon handlebar, width: 800mm, Backsweep: 7°, Upsweep: 5°, Rise: 20mm, Stem length: 50, 75mm

  • Tige de selle

    SRAM Reverb AXS Dropper post, Aluminum 7075-T6, 0 offset, Ø31,6, 150mm travel

  • Selle

    Fizik Terra Ridon X5, Steel rails, length: 255mm, width: 145mm

  • Patte de dérailleur

    Universal Derailleur Hanger

  • Roues

    DT Swiss H1900 Spline 29"/27,5", 15x110, Boost 12x148mm, TLR, XD Rear Hub, 6 Bolts, internal width 30mm

  • Dérailleur avant

    EC AXS POD Ultimate Right/Left Bridge W/MMX

  • Dérailleur arrière

    SRAM XX AXS Eagle T-TYPE, 12s

  • Pédalier

    XX Eagle, SRAM Powertrain ISIS Drive Carbon Cranks, length: 165mm

  • Chaîne

    SRAM EAGLE 70 T-TYPE, 120 Links

  • Cassette

    CS XS1275 Eagle, T-TYPE, 10-52T

  • Frein

    SRAM Maven Ultimate Stealth, 4 Piston

  • Moteur

    SRAM Eagle Powertrain, 680W, 90Nm

  • Batterie

    SRAM Eagle Powertrain Full Size, 720WH, Integrated and Slidable

  • Afficheur

    SRAM Eagle Powertrain AXS Bridge Display

  • Chargeur

    Eagle Powertrain Charger, EU/UK/US Plug Supplied

  • *Nous nous réservons le droit de modifier les informations et les composants des produits qui apparaissent sur ce site Web sans préavis, y compris les équipements, les spécifications, les modèles, les couleurs et les matériaux.

Géométrie

berria-production/frames/26.01.04/10._STRATOS.png

1

Tube de selle

400 mm

2

Tube horizontal

582 mm

3

Angle avant

64.5°

4

Angle du tube de selle

76°

5

Empattement

1208 mm

6

Cosse

450 mm

7

Tube avant

90 mm

8

Patte de fixation du pédalier

-25/-6 mm

9

Trail

131.5 mm

10

Avance de la fourche

44 mm

11

Longueur de la fourche

576 mm

12

Reach

430 mm

13

Stack

610 mm

1

Tube de selle

M mm

2

Tube horizontal

610 mm

3

Angle avant

64.5°

4

Angle du tube de selle

76°

5

Empattement

1239 mm

6

Cosse

450 mm

7

Tube avant

105 mm

8

Patte de fixation du pédalier

-25/-6 mm

9

Trail

131.5 mm

10

Avance de la fourche

44 mm

11

Longueur de la fourche

576 mm

12

Reach

455 mm

13

Stack

623 mm

1

Tube de selle

L mm

2

Tube horizontal

650 mm

3

Angle avant

64.5°

4

Angle du tube de selle

76°

5

Empattement

1280 mm

6

Cosse

450 mm

7

Tube avant

120 mm

8

Patte de fixation du pédalier

-25/-6 mm

9

Trail

131.5 mm

10

Avance de la fourche

44 mm

11

Longueur de la fourche

576 mm

12

Reach

490 mm

13

Stack

637 mm

Technologies

berria-production/technologies/6de25a18-a36b-4a6c-ac2f-855547899893/Y-LINK_895f69d5-fd38-4caf-bd40-2a33b5ef59c8.svg
berria-production/technologies/6de25a18-a36b-4a6c-ac2f-855547899893/Y-LINK_895f69d5-fd38-4caf-bd40-2a33b5ef59c8.svg

"Y-LINK, the custom suspension system for Stratos, develops 160mm of travel and has unsurpassed traction capacity, as well as great handling thanks to the 27.5” tire on the rear wheel. The Y-LINK system damper adjustment is specific to STRATOS kinematics; Anticipating a sensitive, progressive and precise system, it achieves an incredible absorption capacity against large and small impacts together with an exceptional harmony in its operation, transmitting driving confidence and total control when braking. At the same time, the Y-LINK suspension has been developed to ride on all types of terrain and thanks to its neutral Anti-squat, it will allow you to face flat or uphill sections with maximum comfort and dynamism."

berria-production/technologies/ics2/ics2.svg
berria-production/technologies/ics2/ics2.svg

The completely internal ICS2 wiring system achieves unbeatable integration and aesthetics, as well as protecting the system against all external agents that may affect its functionality.

berria-production/technologies/3712e119-47d0-4594-8353-f105b6a59968/EPS_a41ae669-c67f-40b7-a0b6-63982dedd41f.svg
berria-production/technologies/3712e119-47d0-4594-8353-f105b6a59968/EPS_a41ae669-c67f-40b7-a0b6-63982dedd41f.svg

EPS is the inner core made of a self-formulated polystyrene that acts by expanding inside the frame during the curing phase. During this process, the temperature and pressure are controlled to guarantee the carbon compaction process in its different zones. This innovative system allows optimal carbon stratification and the elimination of excess resin. With EPS you get a high quality frame with a compact, strengthful and lightweight structure.

berria-production/technologies/e17d796c-da41-41c9-a7f9-6ecff0a3afcb/HM3X-1.png
berria-production/technologies/e17d796c-da41-41c9-a7f9-6ecff0a3afcb/HM3X-1.png

HM3X carbon features three types of high-modulus carbon fibres: Toray T700 and T800, and Toray T1100G. The inclusion of T1100G fibres improves the golden stiffness-to-weight ratio, making it a perfect material for the highest performance bikes. Our engineers apply these fibres in unique orientations that boost lateral rigidity without sacrificing ride quality and handling.

berria-production/technologies/3fc5e540-4886-4ecb-8acd-1afd0eb1898d/MACH-R_Nanotech_d9b9a3cf-c9d7-47f5-8f3e-1bcf23d98b25.svg
berria-production/technologies/3fc5e540-4886-4ecb-8acd-1afd0eb1898d/MACH-R_Nanotech_d9b9a3cf-c9d7-47f5-8f3e-1bcf23d98b25.svg

To deal with the additional forces and high-frequency vibrations that a motor and battery system exert on a carbon frameset, we use MACH-R Nanotech resin. This special resin bonds the Toray fibres of HM2X carbon together, providing the superior mechanical strength required for an electric motorised frame, improving frame strength, resilience and long-term lifespan.

berria-production/technologies/monocoque/monocoque.svg
berria-production/technologies/monocoque/monocoque.svg

La technologie monocoque permet de fabriquer le triangle avant en une seule pièce à l'aide d'un protocole de cuisson spécifique et de glissières de moulage internes en acier spécial de différentes qualités. Cette technologie est utilisée pour réaliser des cadres où la résistance, la légèreté et la rigidité prévalent.

Taille: S / Couleur: CUSTOMIZE

10.999,00€
